2027 Jeep Gladiator Specs
One V6, one 8-speed automatic and four-wheel drive, with the dimensions, weights and capacities for every 2027 Gladiator trim.
Key Numbers
The 2027 Gladiator is a 218-inch-long mid-size pickup with a 3.6L V6 making 285 hp, a 5-foot bed and four-wheel drive on every trim, and the specs below break that down by trim. The same hardware sits under every Gladiator at Jeep Portsmouth, so shoppers from Exeter, Dover, Somersworth and Rochester can compare trims on weight, clearance and towing rather than on power.
One engine powers every 2027 Gladiator: a 3.6L V6 with variable valve timing and engine stop/start, paired with an 8-speed automatic.
| Specification | 3.6L V6 |
|---|---|
| Horsepower | 285 hp at 6,400 rpm |
| Torque | 260 lb-ft at 4,400 rpm |
| Valves and compression | 24 valves, 11.3 to 1 compression ratio |
| Bore and stroke | 96.0 mm by 83.0 mm |
| Transmission | 8-speed automatic |
| Drive | Four-wheel drive, part-time: Command-Trac on most trims, 4:1 Rock-Trac on the Rubicon |
| Fuel | Regular unleaded, 87 octane |
Axle ratios depend on the trim: the Sport S and Willys use a 3.73 ratio, and the Rubicon and Mojave use a 4.10 ratio for stronger pulling at low speed.
The Gladiator measures 218 inches long on a 137.3-inch wheelbase and 73.8 inches wide without mirrors. Turning diameter is 44.5 feet on the Sport S, Willys, Sahara and Rewind and 44.7 feet on the Rubicon, Mojave and their X trims.
| Dimension | Measurement |
|---|---|
| Overall length | 218 inches |
| Width without mirrors | 73.8 inches |
| Wheelbase | 137.3 inches |
| Height | 76.1 inches on the Mojave; the other trims sit a little lower |
| Turning diameter | 44.5 to 44.7 feet by trim |
| Bed length | 60.3 inches (5-foot steel bed) |
| Trim | Curb weight | Gross vehicle weight rating |
|---|---|---|
| Sport S | 4,695 pounds | 5,800 pounds |
| Willys | 4,860 pounds | on the truck's label |
| Sahara | 4,695 pounds | on the truck's label |
| Rewind | 4,695 pounds | on the truck's label |
| Rubicon | 5,031 pounds | 6,250 pounds |
| Mojave and Mojave X | 5,042 pounds | 6,250 pounds |
| Trim | Ground clearance | Approach angle | Departure angle | Breakover angle |
|---|---|---|---|---|
| Sport S, Willys, Sahara, Rewind | 10.0 inches | see the truck's label | see the truck's label | see the truck's label |
| Rubicon, Rubicon X | 11.1 inches | 43 degrees | 26 degrees | 20 degrees |
| Mojave, Mojave X | 11.6 inches | 45 degrees | 26 degrees | 21 degrees |
The Gladiator is a four-door crew cab with 103 cubic feet of passenger volume and room for five.
| Measurement | Front row | Rear row |
|---|---|---|
| Headroom | 42.8 inches (40.8 on the Mojave X and Rubicon X) | 42.8 inches |
| Legroom | 41.2 inches | 38.3 inches |
| Shoulder room | 55.7 inches | 55.7 inches |
| Passenger volume | 103 cubic feet, seating for five | |
The rear seat splits and folds forward, and the Mojave X adds a lockable storage bin under the rear seat. Behind the cab, the 5-foot bed handles loads the cabin cannot, with trail rails, a roll-up tonneau cover and a 115-volt outlet available on the X trims.
Jeep rates the Gladiator at up to 7,700 lbs of towing and up to 1,720 lbs of payload when properly equipped, on the four-door crew cab with four-wheel drive. Base ratings by trim are below.
| Trim | Base towing (crew cab 4x4) | Base payload (crew cab 4x4) |
|---|---|---|
| Sport S, Sahara, Rewind | 4,500 lbs | 1,025 pounds |
| Willys | 6,000 lbs | 1,025 pounds |
| Mojave, Mojave X | 6,000 lbs | 1,100 pounds |
| Rubicon, Rubicon X | 7,000 lbs | 1,200 pounds |
Payload on the crew cab 4x4 falls as options add weight, which is why a Rubicon with a factory equipment group can list a lower payload than the base figure. The Towing page covers trailer brakes, hitch advice and break-in rules.
Every Gladiator rides on 17 by 7.5 inch wheels with four-wheel disc brakes, ABS and brake assist. Tire choice follows the trim.
| Trim | Tires |
|---|---|
| Sport S | 245/75R17 all-terrain |
| Willys | 255/75R17 mud-terrain |
| Rubicon, Rubicon X | 285/70R17 all-terrain |
| Mojave, Mojave X | 285/70R17 all-terrain |
EPA rates the 2027 Gladiator at 17 mpg city, 22 highway and 19 combined, per fueleconomy.gov, the same on every trim because there is one configuration. It runs on regular gasoline from a 22-gallon tank.
| Measure | Rating |
|---|---|
| City | 17 mpg |
| Highway | 22 mpg |
| Combined | 19 mpg |
| Fuel tank | 22 gallons |
S means standard and O means available on that trim. The Trims page covers every trim in full.
| Feature | Sport S | Willys | Sahara | Rewind | Rubicon | Mojave | Mojave X | Rubicon X |
|---|---|---|---|---|---|---|---|---|
| 12.3-inch Uconnect 5 screen | S | S | S | S | S | S | S | S |
| Apple CarPlay and Android Auto | S | S | S | S | S | S | S | S |
| Navigation | O | O | O | O | S | S | S | S |
| Heated steering wheel | O | O | S | S | S | S | S | S |
| Remote start | O | O | S | S | O | O | S | S |
| Leather seats | not std | not std | S | S | O | O | S | S |
| Power front seats | not std | not std | S | S | O | O | S | S |
| Blind-spot alert | O | O | O | O | O | O | S | S |
| Top-view camera | not std | not std | not std | not std | O | O | S | S |
Every 2027 Gladiator carries electronic stability control, traction control, electronic roll mitigation, advanced multistage front air bags, side air bags, front seat-mounted side air bags and a rear camera. The Rubicon, Mojave and their X trims add full-speed forward-collision warning, advanced brake assist and adaptive cruise control with stop as standard equipment, and blind-spot detection is standard on the Mojave X and Rubicon X.
Coverage starts with a basic warranty of 3 years or 36,000 miles and a powertrain warranty of 5 years or 60,000 miles.
| Coverage | Term |
|---|---|
| Basic limited warranty | 3 years / 36,000 miles |
| Powertrain limited warranty | 5 years / 60,000 miles |
| Corrosion perforation | 5 years / unlimited miles |
| Roadside assistance | 5 years / 60,000 miles |
Service intervals and ownership details are on the Maintenance and Service page.
At 218 inches, the Gladiator is longer than a typical garage bay for a compact car, so measure before you commit. The table turns the numbers into decisions.
| Number | What it means |
|---|---|
| 218 inches long | Just over 18 feet, so it fits a standard two-car garage in Exeter or Dover with room to walk around, but a tight single bay needs a measurement. |
| 73.8 inches wide without mirrors | About 6 feet 2 inches, a comfortable fit for a standard garage door, a Rochester driveway and a tight parking space. |
| 44.5 to 44.7 feet turning diameter | A wide circle, so U-turns on narrow Seacoast roads take a three-point turn. |
| 11.1 to 11.6 inches clearance | Clears frost heaves and washouts that scrape lower trucks. |
| 38.3 inches rear legroom | Adults fit in the back seat for a run to Seabrook, with room for a child seat. |
| 60.3-inch bed | Carries a pair of mountain bikes on end behind the cab. |
The 2027 Gladiator is 218 inches long on a 137.3-inch wheelbase, and 73.8 inches wide without mirrors.
Curb weight runs from 4,695 pounds on the Sport S to 5,042 pounds on the Mojave, with the Rubicon at 5,031 pounds and the Willys at 4,860 pounds.
10.0 inches on the Sport S, Willys, Sahara and Rewind, 11.1 inches on the Rubicon and Rubicon X, and 11.6 inches on the Mojave and Mojave X.
44.5 feet on the Sport S, Willys, Sahara and Rewind and 44.7 feet on the Rubicon, Mojave and their X trims.
22 gallons, filled with regular unleaded gasoline.
The Sport S rides on 245/75R17 all-terrain tires, the Willys on 255/75R17 mud-terrain tires, and the Rubicon and Mojave on 285/70R17 all-terrain tires.
Five adults across two rows, with 103 cubic feet of passenger volume in the cabin.
The engine, transmission, dimensions and tow ratings carry over unchanged. See the 2026 Gladiator specs for the previous model year.
